ZHZ409

ZHZ409

Brake Mode: Electromagnetic brake
Total Weight kg: 73kg(Including the battery)
Rated Load kg: 100
Max Speed km/h: 8
Size(mm): 1180*625*1150
Tirefront/rear: 2.80/2.5-4,2.80/2.5-4
Rated Power: 250W/350W
Battery Lead-acid
Qty per 20'/40'H container(pcs): 64/132
contact us
product details

Primary technical parameter of this scooter

Item ZHZ409C ZHZ409 ZHZ413 ZHZ413S ZHZ409 T
Max Speed 8 8 15 15 8
Rated Load 120 100 150 300 100
Total Weight 56kg(implicit battery) 73kg(implicit battery) 108kg(implicit battery) 118kg(implicit battery) 48kg(implicit battery)
Brake Mode Electromagnetic brake Electromagnetic brake Electromagnetic brake Electromagnetic brake Electromagnetic brake
Brake  Performance ≤2 ≤2 ≤2 ≤2.5 ≤2
Parking  Performance 12° 12° 12° 12° 12°
Obstacle  Height ≤65 ≤65 ≥83 ≥83 ≤65
Ditch  Breadth ≤ 100 ≤ 100 ≤ 166 ≤ 166 ≤ 100
Climbing Ability ≤ 12° ≤ 12° ≥12° ≥12° ≤ 12°
Min Turning Radius 0.85 0.85 1.4 1.8 0.85
Distance with full battery km 24± 4 About 24 About 40 About 40 24±4

Dimension of this scooter

Item ZHZ409C ZHZ409 ZHZ413 ZHZ413S ZHZ409 T Description
Total length L 1180 1180 1400 1650 1110 The horizontal distance between the front and rearmost end of the scooter  (including the front and rear bumper)
Total  breadth B 625 625 675 675 625 Horizontal distance between the two outermost sides of the
scooter
Total height H 990 11 50 1280 1245 990 The height from the ground to the peak of the scooter
Di stance between shaft  784 784 845 1095 784 Center distance of the front and rear wheels
Distance to  the  ground  78 60 70 70 60 Connector for front turn of the front axle
Front wheel tread 400 400 570 570 400 The average distance of the front and rear center line of the two wheels
Rear wheel tread 430 430 570 570 430 The average distance of the front and rear center line of the two wheels
Wheel(Rear) 9”x2 . 8” 2.80/2.5-4 4.10/3.5-6 4.10/3.5-6 9”x3” PU Solid tires/pneumatic tires
Wheel(Front) 9”x2.8” 2.80/2.5-4 4.10/3.5-6 4.10/3.5-6 9”x3” PU Solid tires/pneumatic tires

Technical  Parameter  of Electrical  Equipment  and  Rear Axle Assembly of this scooter

Rear Axle Assembly Parameter Description  ZHZ409C ZHZ409 ZHZ413 ZHZ413S ZHZ409T
Rated Voltage 24V 24V 24V 24V 24V
Rated Power 250W 250W/350W 500W/800W 800W 250W
Battery  Rated Capacity  20AH 20Ah 40Ah-50Ah 40Ah-50Ah 20Ah
Rated Voltage 12V 12V 12V 12V 12V
Number  2 2 4 4 2
Charger  Input 110V-240V 50/60HZ 110V-240V 50/60HZ 110V-240V 50/60HZ 110V-240V 50/60HZ 110V-240V 50/60HZ
Output 24V3A 24V3A 24V5A 24V5A 24V2.0A
Controller Model S-Drive 45A/70A S-Drive 45A/70A S-Drive 120A S-Drive 120A 45A
Max Current  45A/70A 70A 120A 120A 45A
